SENTRAL SENAYAN II





SENTRAL SENAYAN II

Building Features :

Official opening February 2008
Total floors 28 Stories + 1 basement
Construction Reinforced concrete core wall and floors with pre-stressed beams, compliant with Indonesian Seismic Design Code for Buildings 2002.
Tempered glass curtain wall + safety film at ground and mezzanine floor. Granite cladding on ground and mezzanine floor pillars and beams.
Power Supply 4150 kVA main electricity supply
4000 kVA building electrical load assumption
Back-up Power 100 % back-up capacity using 2 x 2000 kVA Mitsubishi generators
Air Conditioning Central water cooling system
24 hours chilled water available for server room
Lighting 500 lux illumination on typical floors
Telecommunication Vertical shaft for fiber optic and standard cable
Lift

14 Passenger Lifts
7 lifts per zone, serving Basement Floor

Low Zone, GF – 16/F
20 persons/1350 kg load capacity 150m/min

High Zone, 16/F – 28/F
20 persons/1350 kg load capacity 240m/min

1 Service Lift, Basement – 28/F
24 persons/1600 kg load capacity 150m/min
Fire & Safety Heat and smoke detector alarms, automatic fire alarm, fire hydrant and fire extinguishers, sprinkler system, emergency lighting, exit signs, public address system, 2 fire stairs with double handrails, emergency lighting and pressurized fresh air.
Executive Toilet Available per floor, 3/F – 28/F, with shower cubical and hot water
Public Toilet Available per floor, GF – 28/F
Pantry & Ablution Available per floor, 2/F (mezzanine floor) – 28/F
Car Parking Available in car park building 1, 7 floors, approximately 700 lots and Plaza Senayan’s car park building.
  Sentral Senayan II
Developer & Manager PT Senayan Trikarya Sempana
Main Contractor PT Kajima Indonesia
Design architects & Engineers Kajima Design, Japan
Kajima Design Asia, Singapore
Project Architects PT Airmas Asri
Structural Engineers PT Wiratman & Associates
M/E Engineers PT Arnan Pratama Consultant
